FDA Standard Industrial Conveyor Belt Metal Detector for Food
Industry
Description
MCD-F500QF is new arrival food metal detector.Not only it has
MCD-F500QD and MCD-F500QE all advantages.like touch screen,10 level
adjustable sensitivity and memory 10 kinds of products etc.But also
it has more higher reliablity and stablity on check products with
water and salt.
MCD-F500QF this machine is widely used in the detection of meat,
mushrooms, candy, drinks, food, fruits and vegetables,
dairy products, aquatic products, health products, additives and
flavorings and other food-ferrous metals and non-ferrous metal
impurities
Quick detail
Detection width : | 45-80 cm, Customized |
Detection height: | 10-50cm Customized |
Detection sensitivity: | 0.6mm-3.0mm iron ball, 1.5-5.0 Stainless steel |
Alarm mode: | The buzzer alarm, the motor automatically stop |
Transfer speed: | 40 meter / mins |
Power: | 100-265VAC, 50-60Hz |
Size: | (150-170)cm(L)*(80-90)cm(W)*(85-120)cm(H) |
Application
it can also be used for the detection of metallic impurities in
chemicals, rubber, plastics, textiles, leather, chemical fiber,
toys as well as for the detection of metallic impurities in
pharmaceuticals, health products, biological products, cosmetics,
gifts, packaging, papers, and so on.
Product Parameter
| Model | MCD-F500QF |
|---|
| Aperture Width (mm) | 90 | 120 | 150 | 200 | 250 | 300 | 350 | 400 |
| Aperture Height (mm) | 300 | 300 | 400 | 400 | 500 | 500 | 600 | 600 |
| Detection Sensitivity (mm) | Fe | ≥0.6 | ≥0.7 | ≥0.8 | ≥1.0 | ≥1.5 | ≥2.5 | ≥3.0 | ≥3.5 |
| SUS | ≥1.2 | ≥1.5 | ≥2.0 | ≥2.5 | ≥3.0 | ≥5.0 | ≥6.0 | ≥7.0 |
| Belt Width (mm) | 280 | 380 | 480 | 580 |
| Table Height (mm) | 700 |
| Loading Capacity (kg) | 0-100 |
| Power Supply | 100-265V AC, 50-60Hz |
Notice:
1. Technical parameter above namely is the result of sensitivity by
inspecting only the test sample on the belt.
2. Sensitivity would be affected according to the products being
inspected and working environment.
3. Requirement for different size by customers can be fulfilled. |
