Super flexible long range Under Vehicle Inspection Camera with Big
LCD Screen
Product Introduction:
Thank you for using the product! It is our latest developed HD
video searching system.
With state-of-art innovation technology, it helps security
personnel to check clearly on front video
display the spaces where are narrow, dark and cannot be reached by
naked eyes. It will simplify
troublesome inspection work and help save plenty of valuable time,
improving security check efficiency.
The product uses high-capacity Lithium battery for power supply
which lasts 6 hours,avoiding frequent
battery replacements. The standard aluminum-alloy carry case is
solid enough to prevent equipment
from damage by drop, shock or press. For detailed instructions,
please refer to the operation manual.
Product Parameters:
Waterproof Camera
- 1. Dimension: 23mmx50mm.
- 2. Flexible pipe: 500mm
- 3. Camera casing:Stainless steel 304
- 4. Camera lens: Sapphire blue
- 5. Sensor dimension:1/4 inch
- 6. Senor pixel:PAL@720X576/NTSC: 720X480
- 7. Lens visible angle: 120 degrees
- 8. Camera adjustable angle: Arbitrary angle
- 9. Camera light source: 12 LEDs10.
- 10. Waterproof standard: IP68
- 11. Working voltage: DC 12V,
- 12. working current: 100mA
- 13. Rod Max length: 3.1m
- 14. Working temperature:-10℃-50℃
LCD Screen:
- 1. LCD dimension: 4.3-inch, 16:9
- 2. Resolution:480*320*RGB
- 3. Power supply:5V DC
- 4. SNR:85dB
- 5. USB:2.0(speed)
- 6. Output:20Hz---20KHz
- 7. Connecting Rod Length:3.2M
- 8. Supplementary lighting: 12LEDs
- 9. N.W: 1250G
- 10. G.W:5.8KG
- 11. Package Size: 110*30*30CM(2pcs/ctn)
Feature and Application:
High definition flexible hose camera, suitable for different angles
and special occasions,
equipped with 4.3 inch LCD screen display multimedia storage image
playback, showed more clear,
with infrared light supplement can be used for the dark place or
use at night, portable-type pipe,
A single-hand operation to check the height. Applied to check the
car table under stools or container
and others special occasions if they are normal, security
antiterrorism after the earthquake
search tool life.
