Security X Ray Inspection Machine Oil Cooling High Resolution Color

    Buy cheap Security X Ray Inspection Machine Oil Cooling High Resolution Color from wholesalers

    Buy cheap Security X Ray Inspection Machine Oil Cooling High Resolution Color from wholesalers
    • Buy cheap Security X Ray Inspection Machine Oil Cooling High Resolution Color from wholesalers

    Security X Ray Inspection Machine Oil Cooling High Resolution Color

    Ask Lasest Price
    Brand Name : MCD
    Model Number : MCD-6550
    Certification : ISO , CE
    Price : Negotiable
    Payment Terms : T/T , Western Union , L/C
    Supply Ability : 300 set/month
    Delivery Time : Normally within 5 working days
    MOQ : 1set
    • Product Details
    • Company Profile

    Security X Ray Inspection Machine Oil Cooling High Resolution Color

    Security X Ray Inspection Machine Oil Cooling High Resolution Color


    Description:


    X-ray Luggage Scanner MCD-6550 is widely used in the factory testing of security products and business units such as: electronic factories, shoe factories, toy factories, courts, railway stations, and event bag, line security management package.


    Parameter :


    Tunnel Size650(W)*500(H)mm
    Conveyor Speed0.22m/s
    Conveyor Max Load170kg
    Dose per Inspection<1.4Gy/h
    Resolution< 0.0787mm Copper Wire
    Spatial resolution Leveldia1.0mm
    Verticaldia1.0mm
    Penetrate resolutiondia 0.254mm
    Penetration34mm Steel
    Film SafetyGuarantee ISO1600 Film
    X-ray Leakage<0.05 μGy/h (at a distance of 5cm From external housing)

    X-Ray generator:


    Generate direct: Upwar

    Generate anger: 80 degree

    Anode Voltage: 100~160Kv

    Anode power: 0.4 to 1.2mA

    Cooling / Duty Cycle: Oil Cooling /100%


    Installation Data:


    Operation temperature/Humidity0°C-45°C/20%-95%(non-condensing)
    Storage Temperature/Humidity-20°C-60°C/20%-95%(non-condensing)
    Operation Power220VAC(±10%)50±3Hz
    Power Consumption1.0 KW (max), 0.7KW(working)
    Noise:<58db

    Image System


    X-ray SensorL-Shaped Photodiode Array (monoenergetic) , 12bit Deep
    MonitorHigh Resolution Color, LCD Accord, 17 inch
    Detector2
    Color displayfull color
    Image Processing

    Edge enhancement, image strengthening, Image lightening,

    reducing darkening, image returning, image retrieval.

    Image Grey Level4096
    Image Max Resolution1024 * 1280 pixel
    Image Processing24bit for processing real time
    Image storageStorage 60000 pictures in real time
    Zones & Zoom

    1-9 Image regions, 2,4,8,16 Times Enlarge, Whole screen

    continuous observation

    Multi-energeti distinguish objects

    organic objects in orange,inorganic objects in blue,

    mixture in green

    High-energy/low energy

    switch from high energy to low energy


    Applications:

    • Commercial buildings
    • Factories
    • Courthouses
    • Embassies
    • Government buildings
    • Military installations
    • Prisons
    • Hotels
    • Schools
    • Convention centers
    • Security checkpoints

    Competitive Advantage:

    • Innovative & Economical

    • World Class Reliability
    • Long-Term Flexibility
    • Ease of Use Increases Efficiencies
    • Ease of Maintenance
    • Competitive Price and Professional Service


    Shipping Means

    1. By express (3-5days, most expensive)
    2. By air (5-7days, expensive)
    3. By sea (15-28days, cheapest)

    MCD has been supplying quality products worldwide for over,40 countries, 10 years, with wide range product line consists of 6 groups, includes:

    • X-ray luggage scanner
    • Walkthrough metal detector gate
    • Food metal detector
    • Underground metal detector
    • Hand-held metal detector
    • Under Vehicle search system
